Ningbo Marshine Power Technology Co.,Ltd sales@marshine.net 86-13777009159
Product Details
Place of Origin: China
Brand Name: MARSHINE
Certification: CE UL ROHS
Model Number: SE8
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Price: usd, 90-300, pcs
Packaging Details: WOOD BOX , PALLET
Delivery Time: 15-30DAY
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200 CONTAINER/YEAR
Condition Of The Item: |
New |
Feature: |
Fire / Flame Retardant |
Size(mm): |
100 - 3000 |
Flange(mm): |
200 - 750 |
Application Of The Item: |
Cabling System |
Weight(kg): |
100 - 500 |
Color: |
Customer Requirement |
Transport Package: |
With Outer Lagging / In Bulk |
Specification: |
Iron / Stainless Steel |
Trademarks: |
MARSHINE |
Original Place: |
China |
HS Code: |
8479909090 |
Supply Ability: |
19000 PCS / Month |
Type Of The Item: |
Cable Reel |
Certification: |
CCC |
Customized: |
Non - Customized |
Condition Of The Item: |
New |
Feature: |
Fire / Flame Retardant |
Size(mm): |
100 - 3000 |
Flange(mm): |
200 - 750 |
Application Of The Item: |
Cabling System |
Weight(kg): |
100 - 500 |
Color: |
Customer Requirement |
Transport Package: |
With Outer Lagging / In Bulk |
Specification: |
Iron / Stainless Steel |
Trademarks: |
MARSHINE |
Original Place: |
China |
HS Code: |
8479909090 |
Supply Ability: |
19000 PCS / Month |
Type Of The Item: |
Cable Reel |
Certification: |
CCC |
Customized: |
Non - Customized |
High Speed Double Steel Reel for Cable Stranding Machine
the product is manufactured from common carbon steel Q235 thick plate through assembly, welding, and machine finishing in accordance with GB4004-83, JB/T7600.3-94, and DIN46395 standards. Our Marshine's High Speed Double Steel Reel for Cable Stranding Machine boasts high bobbin rigidity and precision. Dynamic testing has confirmed stable high-speed operation, making it suitable for high-speed wire-drawing and wire-stranding machines.
This versatile product is available as a skeleton cable reel, steel cable reel, wire spool, steel cable drum, cable spool, or metal spool.
Technical specification
| Serial Number | Specification Model | Lateral Plate Diameter D1 | Major Diameter D2 | Axle Hole Diameter D4 | Carrying Hole Diameter D5 | Center Distance E of Axle Hole and Carrying Hole | External Width L1 | Internal Width L2 |
| 1 | 400 | 400 | 224/250 280 |
125/127 | 28 | 100 | 265 300 |
224 250 |
| 2 | 500 | 500 | 280/315 355 |
125/127 | 28 | 100 | 300 375 |
250 315 |
| 3 | 560 | 560 | 315/355 400 |
125/127 | 28 | 100 | 355 425 |
280 355 |
| 4 | 630 | 630 | 355/400 450 |
125/127 | 28 | 100 | 375 475 |
315 400 |
| 5 | 710 | 710 | 400/450 500 |
250 | 40 | 170 | 425 530 |
355 450 |
| 6 | 800 | 800 | 450/500 560 |
250 | 40 | 170 | 475 600 |
400 500 |
| 7 | 1000 | 1000 | 560/630 710 |
250 | 50 | 250 | 750 | 630 |
| 8 | 1250 | 1250 | 710/800 900 |
250 | 50 | 250 | 950 | 800 |
Key features:
1.for wire production, sustainable use
2.match wire drawing machine
3.many models
4.large loading and good dynamic balance
5.custom special size
Mainly Applied in:
1. Optical fiber cable
2. Data cables
3. Communication cables
4. Power cables
5. Enamel wire
6. Tinned wires
7. Welding wires
8. Ribbon and tape
9. Rope, zipper, bandage
Note:
1.Steel Processed Reel
2.In accordance with GB4004-83, JB/T7600.3-94 and DlN46395 standards
3.Skeleton Cable Reel, steel cable reel,wire spool, steel cable drum and metal spool.
To support the Transmission work, Marshine Power has Cable Reel Spool And Stand,Cable Take Up Machine, Hydraulic Cable Tensioner, Cable Drum Trailer,
