Product Details
Place of Origin: China
Brand Name: MARSHINE
Certification: CE UL ROHS
Model Number: MAR-YZ2×40B
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Price: US$10000-US$100000
Packaging Details: Wooden Box, Wooden Pallet
Delivery Time: 15-30DAY
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200 CONTAINER/YEAR
Condition: |
New |
Feature: |
Fire/Flame Retardant |
Max Tension: |
2X40/1X80 |
Weight: |
4850 |
Bottom Of Groove Diameter: |
1500 |
Engine Power/Speed: |
51/2500 |
Dimensions: |
4.5X2.2X2.8 |
Continuous Tension: |
2X35/1X70 |
Max Speed Back: |
2X1.5 |
Transport Package: |
Carton Box |
Specification: |
2X40/1X80 |
HS Code: |
8467890000 |
Supply Ability: |
100 Sets Per Month |
Package Size: |
450.00cm * 220.00cm * 280.00cm |
Package Gross Weight: |
4850.000kg |
Type: |
Hydraulic Tensioner |
Certification: |
CE, ISO |
Customized: |
Customized |
Shipping Cost: |
About Shipping Cost And Estimated Delivery Time. |
Currency: |
US$ |
Return&refunds: |
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Condition: |
New |
Feature: |
Fire/Flame Retardant |
Max Tension: |
2X40/1X80 |
Weight: |
4850 |
Bottom Of Groove Diameter: |
1500 |
Engine Power/Speed: |
51/2500 |
Dimensions: |
4.5X2.2X2.8 |
Continuous Tension: |
2X35/1X70 |
Max Speed Back: |
2X1.5 |
Transport Package: |
Carton Box |
Specification: |
2X40/1X80 |
HS Code: |
8467890000 |
Supply Ability: |
100 Sets Per Month |
Package Size: |
450.00cm * 220.00cm * 280.00cm |
Package Gross Weight: |
4850.000kg |
Type: |
Hydraulic Tensioner |
Certification: |
CE, ISO |
Customized: |
Customized |
Shipping Cost: |
About Shipping Cost And Estimated Delivery Time. |
Currency: |
US$ |
Return&refunds: |
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Transmission Line Cable Tension Stringing Equipment Diesel Engine Hydraulic Tensioner with 80kn Capacity
Essential Parameters
Model | MAR-YZ2*40B Hydraulic Tensioner |
Maximum Tension (kN) | 2× 40 or 1× 80 |
Continuous Tension (kN) | 2× 35 or 1× 70 |
Maximum Speed (km/h) | 5 |
Bullwheel Bottom of Groove Diameter (mm) | Φ1500 |
Number of Grooves | 2× 5 |
Maximum Pullback (kN) | 2× 40 or 1× 80 |
Maximum Speedback (km/h) | 2× 1.5 |
Maximum Diameter of Suitable Conductor (mm) | Φ40 |
Engine Power / Speed (kW/rpm) | 51/2500 |
Dimensions (mm) | 4500 × 2200 × 2800 |
Weight (kg) | 4850 |
Engine | Beinei Deutz air cooled diesel engine |
Main Pump/Motor | Rexroth |
Reducer | RR (Italian) |
Main Hydraulic Valve | Rexroth |
Radiator | AKG |
Hydraulic Instrument | WIKA |
Option | If use Deutz (Germany) diesel engine,the model is MAR-YZ2×40A,item number:07191 |
Others | According to customer requirement, our MAR-YZ2×40B Hydraulic Tensioner can configure mobile control consoles. It is easy for one operator to control 2 machines simultaneously, which facilitates 4-conductor-stringing operation using two machines. The item number of control consoles is 07193. |
To facilitate transmission work, Marshine Power offers a comprehensive range of OEM equipment, including Tubular Gin Poles, Hydraulic Cable Pullers, Wire Rope Pulley Blocks, Hoisting Tackles, Wire Rope Grippers, Cable Reel Spools, and Stands. All our products adhere to ISO 9001:2008 standards and are distributed to over 50 countries globally.
We provide customization options for items such as emergency restoration towers and crossing structures, and there's no Minimum Order Quantity (MOQ) requirement for safety tools and accessories. Whether you need technical assistance or have specific product requirements, feel free to reach out to us for support. We're here to help. Thank you.
