Product Details
Place of Origin: China
Brand Name: MARSHINE
Certification: CE UL ROHS
Model Number: J240B
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Price: usd, 60-240, pcs
Packaging Details: WOOD BOX , PALLET
Delivery Time: 15-30DAY
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200 CONTAINER/YEAR
Item Condition: |
Brand New |
Feature: |
Insulation |
Conductor Material: |
Aluminum Clad Steel |
Item Material: |
Steel |
Size (mm): |
240-1250 |
Conductor Type: |
Solid |
Applicable Conductor: |
ACSR |
Transport Package: |
Carton Box |
Item Trademark: |
MARSHINE |
Place Of Origin: |
China |
HS Code: |
8467890000 |
Supply Ability: |
20000 PCS / Months |
Type: |
ACSR Conductor |
Certification: |
CE, ISO |
Item Condition: |
Brand New |
Feature: |
Insulation |
Conductor Material: |
Aluminum Clad Steel |
Item Material: |
Steel |
Size (mm): |
240-1250 |
Conductor Type: |
Solid |
Applicable Conductor: |
ACSR |
Transport Package: |
Carton Box |
Item Trademark: |
MARSHINE |
Place Of Origin: |
China |
HS Code: |
8467890000 |
Supply Ability: |
20000 PCS / Months |
Type: |
ACSR Conductor |
Certification: |
CE, ISO |
Estimated Delivery Time for J240B Cable Security Sleeve ACSR Splice Protection Sleeve
This MARSHINE Estimated Delivery Time for J240B Cable Security Sleeve ACSR Splice Protection Sleeve is applicable to compression tubes, in accordance with DL/T758-2001 standard, with hydraulic lap joint splicing accessories. If the size of the compression tube is different from the standard, the size of the splicing sleeve should be indicated in the contract.
Feature: For line stringing and cable pulling, they are designd to avoid torsion strain accumulation.
Notes:
1, Appicable for DL/T758-2001 as stated splicing sleeves.
2, Please writing the dimension of splice in contract if the splicing sleeve differ from standard.
Specifications
| Item Number | Model | Main Dimension (mm) | Applicable Conductor (Max.) | |||
| D | L | d | L1 | |||
| 17201 | J240B | Φ45 | 850 | Φ38 | 530 | LGJ240/55 |
| 17202 | J300B | Φ51 | 940 | Φ43 | 600 | LGJ300/50 |
| 17203 | J400B | Φ57 | 995 | Φ47 | 655 | LGJ400/50 |
| 17204 | J500B | Φ68 | 1080 | Φ56 | 740 | LGJ500/65 |
| 17205 | J630B | Φ83 | 1180 | Φ63 | 800 | LGJ630/55 |
| 17206 | J720B | Φ83 | 1196 | Φ63 | 816 | LGJ720/50 |
| 17207 | J900B | Φ89 | 1180 | Φ73 | 800 | LGJ900/75 |
| 10208 | J1000B | Φ95 | 1400 | Φ75 | 1020 | LGJ1000/80 |
To support the Transmission work, Marshine Power has Hydraulic Cable Tensioner, Pulley Tackle, Cable Installation Machines And Tools, Cable Stringing Equipments, Cable Tightening Device , Cable reel spool and stand- all are OEM and professionally produced per ISO 9001:2008, which are being sold to over more than 50 countries in the world. Some items like emergency restoration tower and crossing structure, we can customized, and the safety tools and accessories, are not demanded the MOQ. You can freely help you out either Tech issue or Products requirements. Pls contact us. Thanks.
