Ningbo Marshine Power Technology Co.,Ltd sales@marshine.net 86-13777009159
Product Details
Place of Origin: China
Brand Name: MARSHINE
Certification: CE UL ROHS
Model Number: CLJ60
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Price: usd , 650 -12455 ,set
Packaging Details: Wooden Box, Wooden Pallet
Delivery Time: 15-30DAY
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200 CONTAINER/YEAR
Condition: |
New |
Feature: |
Insulation |
Maximum Conveying Force (N): |
700 (Consecutive Adjustable ) |
Conveyor Speed (M/Min): |
8-80 (Consecutive Adjustable ) |
Maximum Oil Pressure (MPa): |
15 |
Hydraulic Oil Flow (L/Min): |
10 |
Gasoline Engine (HP/Rpm): |
6/1800 |
Transport Package: |
Industrial Packing |
Specification: |
87.5kg |
Origin: |
China |
HS Code: |
8477309000 |
Supply Ability: |
5000sets/Month |
Package Size: |
140.00cm * 70.00cm * 85.00cm |
Package Gross Weight: |
125.000kg |
Type: |
Module Connecting Machine |
Certification: |
CE, ISO |
Customized: |
Customized |
Shipping Cost: |
About Shipping Cost And Estimated Delivery Time. |
Currency: |
US$ |
Return&refunds: |
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
Condition: |
New |
Feature: |
Insulation |
Maximum Conveying Force (N): |
700 (Consecutive Adjustable ) |
Conveyor Speed (M/Min): |
8-80 (Consecutive Adjustable ) |
Maximum Oil Pressure (MPa): |
15 |
Hydraulic Oil Flow (L/Min): |
10 |
Gasoline Engine (HP/Rpm): |
6/1800 |
Transport Package: |
Industrial Packing |
Specification: |
87.5kg |
Origin: |
China |
HS Code: |
8477309000 |
Supply Ability: |
5000sets/Month |
Package Size: |
140.00cm * 70.00cm * 85.00cm |
Package Gross Weight: |
125.000kg |
Type: |
Module Connecting Machine |
Certification: |
CE, ISO |
Customized: |
Customized |
Shipping Cost: |
About Shipping Cost And Estimated Delivery Time. |
Currency: |
US$ |
Return&refunds: |
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products. |
|
Item Number |
20401 |
|
Maximum Conveying Force (n) |
700 (consecutive adjustable ) |
|
Conveyor Speed (m/min) |
8-80 (consecutive adjustable ) |
|
Diameter of Applicable Cable (mm) |
Φ10-24.3 |
|
Diameter of Applicable Silicon Core Pipe (outer diameter /inner diameter) (mm) |
Φ26/Φ32, Φ28/Φ34, Φ33/Φ40, Φ38/Φ46, Φ42/Φ50 |
|
Overall Dimension (mm): |
1390× 700× 850 |
|
Weight (kg) |
125 |
|
Air Displacement of the Matched Air Compressor (m3/min) |
Upwards of 10m3/min |
|
Air Pressure of the Matched Air Compressor (MPa) |
Upwards 1MPa |
Detailed Data of Hydraulic Pump Station
|
Maximum Oil Pressure (MPa) |
15 |
|
Hydraulic Oil Flow (L/min) |
10 |
|
Gasoline Engine (HP/rpm) |
6/1800 |
|
Length of Rubber Hose (m) |
5 |
|
Dimension (mm) |
780× 470× 780 |
|
Weight (kg) |
87.5 |
To support transmission operations, Marshine Power offers a comprehensive range of products, including tubular stringing rollers, hydraulic rope tensioners, wire rope pulley blocks, lifting pulleys, wire rope grips, cable drum stands, and brackets. All of these items are OEM and professionally manufactured, complying with ISO 9001:2008 standards, and exported to over 50 countries worldwide. We also provide customization services for certain projects such as emergency tower repairs and cross structures, as well as safety tools and accessories, with no minimum order requirement. Feel free to contact us for assistance with technical inquiries or product specifications. Thank you.
1. Training and Services:
Marshine is a company specializing in the development, design, and manufacturing of construction electrical equipment and tools. We not only produce and sell products that meet international standards, OEM, and custom products, but also provide quality tracking and service monitoring.
2. What about the quality of your products?
Our products are strictly manufactured according to domestic and international standards, and each product undergoes testing before leaving the factory. If you would like to view our quality certifications and various test reports, please consult us.
3. Why choose us?
Because we can provide you with high-quality service, quality products, and reasonable prices. In addition, we can also offer customers smooth delivery and excellent solutions.
4. Customer Inquiry:
If there is an emergency, customers can also use online chat (Skype, WeChat) for faster and better communication. Any inquiries will be replied to within 12 working hours.
5. How to obtain samples?
We can provide free samples for buyers to test, but buyers need to pay for shipping. Existing samples take 2-3 days. If there is no stock, we will notify the delivery date.
6. What about packaging and shipping?
All goods will be securely packaged in plywood boxes for long-distance transportation. We support EXW, FOB, CIF, CFR terms.
Required documents such as packing lists, commercial invoices, bills of lading, air waybills, CO, Form E, Form F, etc., will be provided.
Note: If you cannot find the products you need, please feel free to contact us. We will provide the most favorable quotation as soon as possible after confirming your requirements.
