Product Details
Place of Origin: China
Brand Name: MARSHINE
Certification: CE UL ROHS
Model Number: EC-40
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Price: US$10-US$100
Packaging Details: Wooden Box, Wooden Pallet
Delivery Time: 15-30DAY
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200 CONTAINER/YEAR
Degree Free: |
350 Degree |
Voltage: |
18V |
Armored Cu/Al: |
40, 85, 105mm |
Capacity: |
3.0ah |
Transport Package: |
Wooden Case |
Specification: |
5.5kgetc. |
HS Code: |
8467890000 |
Supply Ability: |
5000 Sets/Month |
Certification: |
ISO, CE |
Condition: |
New |
Automatic Grade: |
Automatic |
Usage: |
Construction, Metallurgy |
Type: |
Hydraulic Cutting Tools |
Style: |
Battery Powered Tools |
Degree Free: |
350 Degree |
Voltage: |
18V |
Armored Cu/Al: |
40, 85, 105mm |
Capacity: |
3.0ah |
Transport Package: |
Wooden Case |
Specification: |
5.5kgetc. |
HS Code: |
8467890000 |
Supply Ability: |
5000 Sets/Month |
Certification: |
ISO, CE |
Condition: |
New |
Automatic Grade: |
Automatic |
Usage: |
Construction, Metallurgy |
Type: |
Hydraulic Cutting Tools |
Style: |
Battery Powered Tools |
Feature:
New head design
One key control
Cutting head rotates 350°
Two stage hydraulics
Shorter charging cycles
Automatic retraction when crimp is completed
Battery power display
Detailed Data
| Item number | 21448 | 21448A | 21448B |
| Model | EC-40 | EC-85 | EC105 |
|
Crimping force |
60KN | 60KN | 120KN |
|
Cutting range |
armored CU/AL cable Φ40mm max |
armored CU/AL cable Φ85mm max |
armored CU/AL cable Φ105mm max |
| Stroke | 40mm | 85mm | 105mm |
| voltage | 18V | 18V | 18V |
| Capacity | 3.0Ah | 3.0Ah | 3.0Ah |
|
Charging time |
2hours | 2hours | 2hours |
| Weight |
approx.N.W5.5KG G.W11.5KG |
approx.N.W8.5KG G.W14.5KG |
approx.N.W13.0KG G.W20KG |
| Package |
lastic box 570*500*130mm |
plastic box 570*500*130mm |
plastic box 570*500*130mm |
