Product Details
Place of Origin: China
Brand Name: MARSHINE
Certification: CE UL ROHS
Model Number: ECTX-300
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Price: usd, 160-280, pcs
Packaging Details: Wooden Box, Wooden Pallet
Delivery Time: 15-30DAY
Payment Terms: T/T, L/C, Western Union
Supply Ability: 200 CONTAINER/YEAR
Stroke (mm): |
17 - 42 Mm |
Copper Terminal (mm2): |
50 - 300 Mm2 |
Aluminum Terminal (mm2): |
35 - 240 Mm2 |
Battery Specification: |
18 V 3 Ah |
Max Compression (Kn): |
60 - 120 Kn |
Transport Package: |
Packaged In Plastic Box |
Trademarks: |
MARSHINE |
Place Of The Origin: |
China |
HS Code: |
8467890000 |
Supply Ability: |
2000 Sets/Month |
Product Type: |
Crimping Pliers |
Product Certification: |
CE , ISO |
Customizable Situation: |
Can Be Customized |
Product Feature: |
Insulation |
Stroke (mm): |
17 - 42 Mm |
Copper Terminal (mm2): |
50 - 300 Mm2 |
Aluminum Terminal (mm2): |
35 - 240 Mm2 |
Battery Specification: |
18 V 3 Ah |
Max Compression (Kn): |
60 - 120 Kn |
Transport Package: |
Packaged In Plastic Box |
Trademarks: |
MARSHINE |
Place Of The Origin: |
China |
HS Code: |
8467890000 |
Supply Ability: |
2000 Sets/Month |
Product Type: |
Crimping Pliers |
Product Certification: |
CE , ISO |
Customizable Situation: |
Can Be Customized |
Product Feature: |
Insulation |
Detailed Data
Item Number | 16209 | 16209A |
Model | ECTX-300 | ECTX-400 |
Max Compression(kN) | 60 | 120 |
Stroke(mm) | 17 | 42 |
Compress range | Copper Terminal 50-300mm² | Copper Terminal 50-400mm² |
Aluminum Terminal 35-240mm² | Aluminum Terminal 35-300mm² | |
Battery | 18V3Ah | 18V3Ah |
Compression Die Size | Hexagon Die: 50, 70, 95, 120, 150, 15, 240, 300 | Hexagon Die: 50, 70, 95, 120, 150, 185, 240, 300, 400 |
